200 PSI Stainless Pressure Sensor

200 PSI Stainless Pressure Sensor

0-100 PSI Stainless Pressure Sensor

Overview
Plug and play for Holley Avenger, Terminator, HP, and Dominator ECU fuel and oil pressure inputs.

It is not recommended to directly mount a pressure transducer directly to the Engine It is best to remote mount the transducer. Extreme vibration can result in premature failure.

Features:

• Plug and play for both fuel and oil pressure inputs with Holley EFI systems (Terminator systems monitor fuel pressure only)
• Stainless steel construction
• Comes with mating connector for custom configurations
• Linear voltage output of 0.5-4.5 volts

Details:

• Body Diameter: .875"
• Body Length: 2.558"
• Inlet Size: 1/8 inch NPT
• Linear voltage output: .5 - 4.5 Volts
• Material: Stainless Steel
• Pressure Range: 0-200 PSI
• reference voltage required: 5 Volts

Links
Instruction Sheet
