Fully Bolt-On FKF Tube Style Traction Bars for 3.5" or 4" Axle Diameter Dodge Trucks

These bars use 2" .250" wall DOM steel tubing, 1/4" HRPO steel mounts, and 1.25" (76,000LB) load-rated heim joints. We are proud to say these bars use some of the highest strength components on the market. In other words, if you bend, crack, or damage these bars or any fabricated component in this kit, we will replace them. NO QUESTIONS ASKED LIFETIME WARRANTY.

Included Components:

• 2 - 2" .250" wall DOM tube traction bars
• 2 - 2" .250 wall DOM tube with HD poly bushing and sleeve
• 2 - 1.25” 12tpi Thread Heim Joint (76,000lbs load rating)
• 4 - Heim Joint misalignment spacers
• 2 - 1/4" Steel rear bolt-on axle mounts
• 2 - 1/4" steel front bolt-on frame brackets
• 2 - Grade 8 5/8"- 4" long bolts
• 2 - Grade 8 3/4"- 4" long bolts
• 2 - Grade 8 5/8" Nuts
• 2 - Grade 8 3/4" Nuts
• 6 - Grade 8 1/2" - 3 1/2" long bolts
• 10 - Grade 8 1/2" nuts
• 20 - 1/2" washers
• 4 - 5/8" washers
• 4 - 3/4" washers
• 2 - 3/16" FelderKustomFab badges
• 4 - Stainless button head badge mounting bolts
• 2 - New 4" Round U-bolts

Available Lengths: Up to 80". Please measure to a flat, unwidened section of your frame. Always measure before ordering, but we recommend:

• Mega Cab/Crew Cab/Single Cab Short Box - 58"
• Crew Cab Long Box - 70"

Please state desired traction bar length and axle diameter in the cart notes.

If you need insight on your axle diameter, please feel free to reach out through our contact form, and we would be happy to help.

The FelderKustomFab badge will come raw brushed stainless steel. If you would like it done in a custom color, please state in the cart notes.

Will not work with aftermarket airbags or rear coil spring-equipped trucks.

Custom powder coat color available for the bars or mounts (select “Custom Color” and state color in dropdown menus). If Raw is selected, these fields can be left empty. See color options: Prismatic Powders Canada

These are built to order; please allow a 2-3 week lead time. ⏳
