Holley EFI Fuel Level GaugeVacuum / Boost - Standard 2-1/16" size - 30" Hg - 30 PSI - CAN - Black Face - Black BezelOverviewThese analog-style gauges are designed specifically...
Vacuum / Boost - Standard 2-1/16" size - 30" Hg - 30 PSI - CAN - Black Face - Black Bezel
Overview These analog-style gauges are designed specifically for use with Holley EFI systems. They are compatible with all Terminator, HP, and Dominator ECU's, allowing them to be installed in a variety of Holley EFI equipped vehicles. CAN-bus communication allows the gauges to daisy chain using the included stereo cables, making installation quick and clean. The required gauge module (P/N 554-130) allows plug and play communication between the ECU and gauges, through a one-wire ECU connection.
Can be used with Sniper ECUs when used in conjunction with module part # 554-130.
Boost ICF MUST be active for this gauge to function!
Easy to install - One plug and play gauge module (P/N 554-130) is required per set of CAN gauges. User can daisy chain as many gauges as they choose; all gauge data supplied through a one-wire ECU connection.
Features:
Wires directly to sending unit, programmable for factory and aftermarket sending units with a range anywhere within 0-300ohms
Includes 12' shielded cable to connect directly to sending unit
270 sweep pointer from 6 to 3 o??????clock makes gauges easy to read at a glance
Pointer is driven by a high-torque internal stepper motor to ensure accurate movement in racing conditions
Adjustable LED warning light allows user to set low trigger points
LED warning light brightness can be configured for both day and night
Spin lock ring threads to back of gauge case for simple and secure gauge mounting
CNC machined billet aluminum bezels with anodized finish ???? Bezels are threaded for easy replacement
Multiple bezel options available separately ???? User can customize the gauges to their preference
