Special Notes Prior to installation, verify all hardware and properly tighten and spring preload is set to 5-10mm(1/4-3/8in). Our technical department is available to answer any other questions. For vehicles...
Prior to installation, verify all hardware and properly tighten and spring preload is set to 5-10mm(1/4-3/8in). Our technical department is available to answer any other questions.
For vehicles not equipped with electronic dampening control
Front damper requires to be remove to turn dampening knob
Damping Levels
16-Level
Height Adjustment
Yes
Spring Rate(Front)
8 kg/mm (448 lbs/inch)
Spring Rate(Rear)
10 kg/mm (560 lbs/inch)
Spring Length(Front)
185 mm
Spring Length(Rear)
200 mm
Front Top Mount
No, Reuse Factory
Rear Top Mount
No, Reuse Factory
Spring Inner Diameter(Front)
62 mm (2.44 inch)
Spring Inner Diameter(Rear)
62 mm (2.44 inch)
Warranty Note
365 days limited warranty from date of purchases, proof requires. Warranty are not transferable.
