1979-1982 Special Notes Prior to installation, verify all hardware and properly tighten and spring preload is set to 5-10mm(1/4-3/8in). Our technical department is available to answer any other questions. Damping...
Prior to installation, verify all hardware and properly tighten and spring preload is set to 5-10mm(1/4-3/8in). Our technical department is available to answer any other questions.
Damping Levels
16-Level
Height Adjustment
Yes
Spring Rate(Front)
8 kg/mm (448 lbs/inch)
Spring Rate(Rear)
5 kg/mm (280 lbs/inch)
Spring Length(Front)
220 mm
Spring Length(Rear)
180 mm
Front Top Mount
Yes, Pillow Ball w/ Camber Plate
Rear Top Mount
Yes, Standard Type
Spring Inner Diameter(Front)
62 mm (2.44 inch)
Spring Inner Diameter(Rear)
80-102 mm
Warranty Note
365 days limited warranty from date of purchases, proof requires. Warranty are not transferable.
