Special Notes Prior to installation, verify all hardware and properly tighten and spring preload is set to 5-10mm(1/4-3/8in). Our technical department is available to answer any other questions. Damping Levels...
Prior to installation, verify all hardware and properly tighten and spring preload is set to 5-10mm(1/4-3/8in). Our technical department is available to answer any other questions.
Damping Levels
32-Level
Height Adjustment
Yes
Spring Rate(Front)
8 kg/mm
Spring Rate(Rear)
6 kg/mm
Spring Length(Front)
200 mm
Spring Length(Rear)
220 mm
Front Top Mount
Yes, Pillow Ball w/ Camber Plate
Rear Top Mount
No, Reuse Factory
Spring Inner Diameter(Front)
62 mm
Spring Inner Diameter(Rear)
62 mm
Warranty Note
365 days limited warranty from date of purchases, proof requires. Warranty are not transferable.
