Product Description: We are proud to bring you our Heavy Duty Tubular 4 Link Upgrade for the Ford Super Duty. These work on stock trucks all the way up to...
We are proud to bring you our Heavy Duty Tubular 4 Link Upgrade for the Ford Super Duty. These work on stock trucks all the way up to 12" of lift. They are completely bolt on utilizing the existing radius arm frame brackets combined with our brackets included in this kit. A 4 link kit improves ride quality and drive-ability compared to the OEM radius arm setup as you now have 2 axis pivot points at the frame so the axle will be free to travel straight up and down as opposed to "twisting" with the single axis radius arm setup. We offer this kit in fixed length and adjustable versions. These fixed length arms come in four different sizes:
Stock to 3" lift
4" to 6" lift
7" to 9" lift
10" to 12" lift
Each size keeps the axle centered with the corresponding amount of lift. The fixed length arms have 5-6 degrees of caster factored into the length and utilize the same High Density Polyurethane Bushings and DOM sleeves as our Dodge control arms.
(*Please note that all kits are build to order. Raw will typically ship in 4 weeks and Black or Powder coated bars will typically ship in 8 weeks. Feel free to call us if you have any questions or concerns regarding build times, thank you.)
Product Finish:
These are offered RAW (bare steel), with black powder coating, or we will shoot any color prismatic powders offers.
For available colors please obtain color code from Prismatic Powder at the link below:
Please note the possibility of shipping damage with custom colors. 2 stage candy colors are not as immune to mishandling by the shipping companies, they do chip much easier than black. We have no issue shooting colors, the shipping companies mishandling the packages does happen however, and is out of our control. All custom color sales are final.
Hardware: This particular kit comes complete with high quality zinc coated Grade 8 hardware which includes locking washers to ensure a fast and easy installed followed by a lifetime of trouble free use.
Instructions: All of our products come complete with detailed step by step install instructions to ensure installation is a breeze. Average install time for this kit is 45-60 minutes.
